Starter BOSCH PN: 0001231018

by Bosch
Dhs. 2,431.66
SKU 1231018

Specifications
Independent aftermarket part(IAM) 0001231018
Designation Starter
Type formula EV(R) 24 V 4, 0 KW
Securing hole 2 10, 5 mm
Fixing hole 1 10, 5 mm
Angle of mounting bore 40°
Number of thread bores 0
Number of teeth 9
Coupling clamp 30
Coupling clamp 50
Angle nose opening 190°
Number of fixing holes 2
Starter design with integrated bearings
Pinion rest position 23, 00 mm
Position of nose right
Flange diameter 82, 5 mm
Position of fixing hole right
Nominal power 4, 000 kW
Nominal voltage 24, 000 V
Rotation direction Clockwise direction of rotation
Length(unpacked) 321, 00 mm
